Ultra-compact and lightweight 60 GHz radar in USB stick format.
Real-time multi-target detection and tracking.
Wide field of view for comprehensive surveillance.
High-resolution distance and speed measurement. Compact format,
low power consumption, easy integration.
Versatile use for embedded and industrial systems.
OPERATIONAL CHARACTERISTICS :
DIMENSIONS: 65x30x20 mm (with case) 60x22x5 mm (without case) WEIGHT: 20g (with case) 6g (without case) INTERFACE: USB FRAME RATE: 20Hz POWER CONSUMPTION: 4W POWER SUPPLY: 5V IP RATING: IP67 OPERATING TEMPERATURE: -40°C / +85°C
PERFORMANCES :
INSTRUMENTED DISTANCE: 0.5 to 100m DETECTION RANGE (At 0°): 120m (Car) 40m (1 pedestrian) 20 (mil.UAV) SEPARATION: < 0.2m ACCURACY: ±0.02m MAXIMUM SPEED: ± 60 km/h SEPARATION: < 0.25 m/s ACCURACY: ± 0.13 m/s NUMBER OF SIMULTANEOUS TARGETS: MAX100 FREQUENCY: 60GHz FIELD OF VIEW: Az: ±60° El: ± 60°
Keywords
Radar
USB Format
Compact
Low Power
Versatile
About
NUSENSE
NUsense is a French company comprised of recognized experts in millimeter wave radar.
Founded in 2024, our areas of expertise cover the entire radar chain: Radar Systems, RF Design, Signal Processing and Radar Measurements.
Our ambition is to democratize the use of radar: our compact and low-power radar products addressa wide range of applications.
