Pull-out capacity: 54 tonnes per anchoring point (equivalent to 100 kg of material)
Operates on all seabed types
Reduced impact on the seabed
Ground bearing pressure lower than a human footstep
Operating fluid: propylene glycol (colourless, water-miscible, ocean-friendly)
Service life: 50 years and more (duplex stainless)

Steps to perform an underwater anchoring:

Positioning
Deployment of the drilling tripod
Adjustment of the legs
Drilling
Injection of natural cement
Anchor test

Environmental benefits of the Temano® anchor:
→ Reduced environmental impact throughout its life cycle

Production / Installation

Operates using food-grade hydraulic fluid
Set in natural cement
Ground pressure exerted by the installation machine is less than that of a human footstep
Low raw material consumption

Use

Fixed anchorage: no slippage possible
Small footprint for better preservation of the seabed
Low carbon footprint during maintenance phases (lightweight installation)

End of life

Can be removed using methods similar to those used for installation

Areas of application:

Boat mooring
Yacht mooring
Defence
Marine renewable energy (floating solar and wind power)
Buoyage
Aquaculture

Keywords

Drilled Anchor
Eco-friendly
Pull-out Resistance
Lightweight Installation
Made In France

About

TEMANO

New Marine Technology

TEMANO designs anchoring and mooring solutions suited to the challenges of Marine Renewable Energy. From floating solar to floating wind, its systems combine strength, durability, and respect for the marine environment. TEMANO uses its expertise to support the development of innovative and sustainable maritime projects.
